Designed for bigger 1S brushless quadcopters, available in seven colors. Featuring motor mounts for easy installation, and an upgraded battery slot, allowing for a bigger capacity 1S battery. This really improves stability and smooths out the flight. Equipped with an F4 1S 5A flight controller, 1102 motors, and 45mm propellers, the Meteor75 Pro Brushless Whoop Frame provides an excellent thrust-to-weight ratio, perfect for 1S HD whoops.

Note: On the way, stay tuned! The Meteor75 Pro Brushless Quadcopter with analog VTX or HD digital VTX is coming soon.

Bullet Points

• Meteor75 Pro Brushless Whoop Frame is durable enough with a lightweight of 7.73g.

• The motor holder uses a bilateral stretching triangular structure, extremely sturdy for motor installation. So, the flight is stable when the quadcopter is at high speed. It is recommended to use motors with a triangular mount, such as 1102 or 0802SE brushless motors.


• The battery slot is bigger. Pilots can use a bigger 1S battery with a larger capacity. We recommend BETAFPV 450mAh 1S battery, BT2.0 550mAh 1S battery.

• The frame is perfect for 45mm propellers like Gemfan 45mm 2-blade or 3-blade props. It greatly improves the thrust for 1S whoops, especially when equipped with an HD digital VTX.

• The Meteor75 Pro Frame is a complete upgrade for pilots who fly Meteor65, Meteor 65 Pro, or Meteor 75 brushless quadcopters. The electronics are compatible, such as the F4 1S 5A flight controller. Just buy 45mm propellers and we recommend 1102 motors for more power.

Specification

• Item: Meteor75 Pro Brushless Whoop Frame

• Material: PP

• Wheelbase: 80.8mm

• Weight: 7.73g

• Color: Black/Blue/Cyan/Yellow/Orange/White/Red

• Motor mount hole: 3-M1.4-φ6.6mm, 1102, 0802SE Brushless Motors

• FC mount hole: 26*26mm, F4 1S 5A FC

Bigger 1S Drone Combo

The Meteor75 Pro frame with 45mm 2-blade or 3-blade props delivers a very precise, nimble, and awesome flight. It is compatible with Meteor 1S series parts and is very easy to exchange and upgrade. With 45mm props, it is the biggest 1S whoop drone currently. It could be perfect for an indoor HD VTX.

Please click to buy 45mm 2-blade or 3-blade propellers.

From Meteor75 to Pro

The Meteor75 Pro frame is bigger than the regular Meteor75. It is compatible with 45mm propellers, which makes the Meteor75 Pro the biggest 1S whoop currently. The motor holder uses a bilateral stretching triangular structure, providing pilots with a more durable and smoother flight experience.

The battery slot has been upgraded and is now wider, with a size of 16.7mm. The Meteor75 Pro frame supports 450mAh and 550mAh 1S batteries. It is recommended to use the BT2.0 450mAh 1S battery, BT2.0 550mAh 1S battery, and other brands' batteries compatible with the slot.

Recommended Parts

• Propellers: 45mm 2-blade/3-blade props

• Motors: 1102 Brushless Motors, 0802SE Brushless Motors

• Batteries: BT2.0 450mAh 1S, BT2.0 550mAh 1S (4PCS)


• Canopy: BETAFPV Micro Canopy, Micro Canopy for HD Camera

• Screws: Meteor Series Motor Mount Screw Pack (40PCS)

• FC: F4 1S 5A FC

Package

• 1 * Meteor75 Pro Brushless Whoop Frame

This micro canopy is specially designed for the Walksnail Avatar Nano Camera, Runcam Nano Lite Camera, or most 14mm nano cameras, and supports 0-45° adjustable camera lens. It features high compatibility with both HD digital VTX (P1 Air Unit) and analog VTX (M03 Analog VTX).

Bullet Points

• The canopy is designed with camera mounting holes for 0-45° lens angle adjustment. It is suitable for the Walksnail Avatar Nano Camera, Runcam Nano Lite Camera, or most 14mm nano cameras.

• Lightweight and available in two colors (White/Black/Blue). Using it with a colored Meteor series frame will be more attractive. Recommended frames for Meteor75 Pro P1, Meteor65 Pro, Meteor75, and Meteor85.


• Designed with an injection molding technique, this canopy is more durable, impact-resistant, and heat-resistant, providing excellent protection for your whoop drone.

• Unique design with three decorative parts resembling a knight, the drone cruises through the air like a scientific spaceship, making it very cool and special. Additionally, the decorative parts are removable for better heat dissipation.

•


Specification

• Item: Micro Canopy for HD Camera

• Material: PP

• Tilt: 0-45°

• Weight: 2.50g (without decorations), 3.28g (with decorations)

• Color: Black/Blue

• Suitable VTX: P1 Air Unit, 1S Walksnail Avatar Mini HD VTX, HDZero Whoop Lite Bundle, M03 25-350mW 5.8G VTX

• Suitable FPV Camera: P1 Camera, Walksnail Avatar Nano Camera, Runcam Nano Lite Camera, or most 14mm nano cameras

• Suitable Frame: Meteor75 Pro, Meteor65 Pro/Meteor75/Meteor85

New Upgrade, High Compatibility

This is the standard canopy for the Meteor75 Brushless Whoop Quadcopter (1S HD Digital VTX) and it is outstanding in many ways. Featuring a hollowed-out design throughout the shell, it allows more air to flow through, greatly reducing the influence of heat on electronic components. Furthermore, using it with the Meteor75 Pro P1, Meteor65 Pro, Meteor75 (Analog), and Meteor85 is a good choice for pilots who want to upgrade their drones with a HD Digital VTX.

Assembly Diagram

The image below is the schematic for this canopy. This canopy is compatible with the 1S Walksnail Avatar Mini HD VTX, HDZero Whoop Lite Bundle, M03 Analog VTX, or most 14mm nano cameras. VTXs from other brands of similar sizes can also be mounted on this canopy.

Recommended Parts

• Quadcopter: Meteor75 Pro P1

• VTX: P1 Air Unit

Package

• 1 * Micro Canopy for HD Camera (White/Black/Blue)

• 3 * Decorative Parts

• 3 * M1.4*3 Screws


• 8 * M1.4*5 Screws

• 3 * M2*4 Screws

Note: The decorative parts for the HD Camera Micro Canopy and the 2022 Micro Camera Canopies are not commonly available, despite their similar appearance.

Here is a new version of the black and red bell motor. The new 1102 brushless motors have been launched for stronger thrust in 1S whoop drones, available in two RPM versions: 18000KV or 22000KV, thus meeting the needs of pilots for different flight uses. This motor is lightweight, weighing 2.79g/piece, and is suitable for most 1S 75mm frames, such as the Meteor75 frame.

Bullet Points

• Adopts ball bearing technology, which effectively reduces friction between bearing surfaces, increases motor lifespan, and improves its efficiency.

• The connecting wire is soldered to the PCB, making it easier for you to repair once disconnected.

• With exquisite manufacturing, it delivers the most incredible power and thrust with the lightest weight of 2.79g, a robust structure, and high-quality materials that allow it to perform like a beast.

• Features dynamic balance and crush-resistant damping rolling, which can effectively eliminate vibration.

• Classic 1102 18000KV Brushless Motors are available in 37mm or 50mm cable versions. 1102 18000KV motors have good performance in efficiency, and the 22000KV version with higher KV value can provide more thrust for aggressive indoor FPV racing. Both classic 1102 18000KV and new 18000KV have the same performance.

•


Specifications

• Height: 15.2mm/13.6mm (2022 Version)

• Weight: 2.95g/pc (18000KV) / 2.79g/pc (22000KV)

• Shaft Diameter: 1.5mm

• Shaft Length: 5mm

• Motor Mount Holes: 3-M1.4-φ6.6

• KV(rpm/V): 18000KV/22000KV

• Input Voltage: 1S Lipo

• Connector & Cables: Micro JST-1.25 3-pin connector with 28AWG cables

1102 18000KV or 22000KV Brushless Motors

1102 18000KV Brushless Motors are the stock motors for Cetus Pro and Meteor75 (1S HD Digital VTX). It offers excellent efficiency for flight endurance, which is very suitable for FPV cruising flight. 1102 22000KV has a higher motor RPM and faster response, allowing the quadcopter to take off with more power at lower throttle. More aggressive and powerful for FPV racing. For pilots who fly 75mm whoop drones with 1102 18000KV motors, it is a good option to switch to 22000KV motors.

Recommended Parts

• Battery: BT2.0 1S 450mAh Battery

• Frame: Meteor75 Frame

• Propellers: 40mm 3-blade props

• Screws: Meteor Series Motor Fixed Screw Pack (40PCS)

• Flight Controller: F4 1S 5A FC / F4 1S 12A AIO Flight Controller

•


Package

• 4 * 1102 Brushless Motors (18000KV or 22000KV)

• 1 * M1.4*4 Screws Pack
